    SUS#304 Walk In Environmental Chamber 20%RH-98%RH Low Humidity

    Ask Lasest Price
    Brand Name : DGBELL
    Model Number : BTHW-6M / BTHW-8M / BTHW-10M / BTHW-15M / BTHW-30M / BTHW-80M
    Certification : ISO-9001:2015
    Price : negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 5000+ sets
    • Product Details
    • Company Profile

    SUS#304 Walk In Environmental Chamber 20%RH-98%RH Low Humidity

    Walk In Test Chamber Can Customizable, ≤±0.5℃ Temperature Fluctuation


    Applications


    This equipment mainly used for electric and electronic products, components and other high low temperature, temperature change, damp heat, etc environment simulation reliability test.


    Features


    Reinforced steel frame structure, external with double sides cold rolled plate electrostatic powder coated materials, internal with SUS#304 high temperature resistant stainless steel. Insulation material adopts fire resistant environment friendly glass fiber thermal insulating material. More than 20% energy saving is achieved & thanks to the introduction of Japan & German advanced refrigerator control technology. Control system and control circuit components are introduced with the famous brand.


    Standard Compliance

    • IEC68-2-1 (GB/T2423.1-2008)

    • IEC68-2-2 (GB/T2423.2-2008)

    • IEC68-2-3 (GB/T2423.3-2006)

    • IEC68-2-30 (GB/T2423.4-2008)

    • IEC68-2-14 (GB/T2423.22-2008)

    • MIL-STD-810D (GJB150.3A-2009)

    • MIL-STD-810D (GJB150..4A-2009)

    • MIL-STD-810D (GJB150.9A-2009)


    Performance parameters


    Temperature Range

    A:0~90℃ B:-20~90℃ C:-40~90℃ D: -70~90℃

    Humidity Range

    20%RH-98%RH Low humidity: Maximum 5%R.H.

    Temperature Fluctuation

    ≤±0.5℃

    Temperature Deviation

    ≤±2℃

    Temperature Uniformity

    ≤±2℃

    Humidity Fluctuation

    ≤±2.5%

    Humidity Deviation

    ≤+2/-3%R.H. (when humidity >75%RH), ≤±5RH% (when humidity <75%RH)

    Heating Rate

    Approx 1~ 3℃/mins,average non-linear ,no load

    Cooling Rate


    Approx 0.5~ 1℃/ mins,average non-linear ,no load

    Temperature Overshoot

    ≤±2℃

    Internal Material

    1.0mm thick SUS#304 high & low temperature resistance stainless steel.

    External Material

    1.2mm thickness High temperature spray powder coated galvanized plate

    Compressor

    Tecumseh (France)-fully air-cooled double-fall cooling compressor. Or Bock (Germany) semi-enclosed air-cooled refrigeration.

    Options

    Dry air purge system, Humidifying water auto purifying and supply system, New air ventilation system, Fire-proof, explosion-proof & alarm system, Low temperature low humidity, low temperature high humidity test requirement, Remote computer, mobile alarm function
